Nidec EQ Series DE4 Close Coupled Pump Full Rated Pool & Spa Motor - EEQK1500

Ahorrar 37%

Your inquiry was submitted successfully. You can expect to hear from us shortly. To expedite the quoting process plesae create an account.
Nidec EEQK1500 EQ Series DE4 Close Coupled Pump Full Rated Pool & Spa Motor; Open Drip proof, 215JMZ, 15 HP, 3-Phase, 208-230/460 V, 40-38/18.8 A, Black
  • Special JMZ Mounting
  • Permanently Lubricated Ball Bearings
  • Black Paint
  • Stainless Steel Ground Lug
  • Premium Efficient, Full Service Factor
Ambient Temperature40° C
Bearing TypePermanently Lubricated Ball
BrandU.S. Motors
Duty CycleContinuous
Enclosure DesignOpen Drip Proof
Finish ColorBlack
Frequency Rating60 Hz
Full Load Amps40-38/18.8 A
HP Rating15
Insulation ClassF
ItemPool & Spa Motor
Length Less Shaft15.00 Inch
Mounting PositionF1 Assembly
Mounting TypeRigid Base
Nominal Efficiency91 %
Number of Speeds1
Overall Length19.25 Inch
SeriesPentair EQ Series
Service Factor1.15
Shaft Diameter1 Inch
Shaft Height5.25 Inch
Shaft Length4.25 Inch
Shaft Material303 Stainless Steel
TypeDE4, Close Coupled Pump, Full Rated
Voltage Rating208-230/460 V
